Master Bond UV15X-6NM-2 Non-Yellowing UV Curable System

Master Bond's UV15X-6NM-2 is well suited for potting and encapsulation applications, and features an elongation exceeding 200% to withstand rigorous thermal cycling.

MasterBond UV15X 6NM 2 5706cd703f4bf
Grey Red2line270x49 10342602

Master Bond UV15X-6NM-2 is a one component UV curing urethane acrylate system formulated for a variety of bonding, sealing, coating and encapsulation applications.

  • Features moderate viscosity
  • Provides flexibility, toughness and abrasion resistance
  • Widely used for fiber-optic, optical, electronic, semiconductor, microelectronic and laser applications
  • Serviceable over wide temperature range of -80-250 F (-62.2-121.1 C)
  • Features an elongation exceeding 200%, which contributes to its ability to withstand rigorous thermal cycling and mechanical shocks
  • Offers chemical resistance, especially to water, cleaning agents and oils
  • Refractive index of 1.50 ensures optical clarity and non-yellowing properties
  • Cures readily in 10-30 seconds when exposed to UV light source
  • Rate of cure depends upon system’s distance from light source, thickness of the section and intensity of light source
  • Not oxygen inhibited
  • Cures can be obtained in sections approaching 1/4 in. thick
  • Reliable electrical and thermal insulator
  • Bonds well to a variety of substrates including glass, plastics - including polycarbonates and acrylics - composites, metals and many types of rubbers
