Hella L4060 LED Series Modules

HELLA Inc. has expanded its 90 mm LED module series with the introduction of the L4060 LED Series.

• Offered in low beam, high beam and fog light modules
• Compactly designed
• Allows up to three light functions in one module without the need for additional electronics
• Low Beam LED module can function as a low-beam only light or a low beam, daytime running and position light combination
• High Beam LED module is available as a high-beam only, a combination with a high beam, daytime running light and position light, or high beam and direction indicator
• Fog Light LED module is available as a front fog-lamp only, as a combination fog lamp, daytime running light and position light, or fog light and cornering light
• Uses high performance LEDs to produce homogenous light output
• Maintenance free
• Capable of operating for up to 15,000 hours
• Daytime running light and position light feature white ring that gives vehicle a striking appearance
• High beam with indicator features an orange ring, which represents the indicator function
• Features ultra light, chip-resistant, 40 x 60 mm (1.57 in. x 2.4 in.) polycarbonate lenses
• Die-cast aluminum housings ensure resistance to stress and wear
• Features low power consumption of 20W
• SAE/DOT approved
• Rated for operation in 12V and 24V vehicle electrical systems
• Incorporates integrated driver electronics for direct replacement of halogen modules
