Curtiss-Wright deploys rapid prototyping electronic throttles for Polaris RZR vehicles

Curtiss-Wright's Industrial division announces the supply of its Williams Controls electronic throttles to Polaris Industries for use on its RANGER and recently-launched RZR XP 1000 vehicles.

Polaris 2014 Rzr 1000 Xp White 3q
800px Curtiss Wright Logosvg 10941485

Curtiss-Wright Corp. announces its Industrial division will be supplying Williams Controls electronic throttles to Polaris Industries for use on its RANGER and recently-launched RZR XP 1000 vehicles. As vehicle volumes increase, Polaris Industries Inc. opts for Williams Controls throttles as part of its decision to move away from conventional push/pull mechanical systems to electronic control.

Engineering teams from both companies worked together for almost eighteen months to re-engineer an existing Williams Controls pedal design, with the resulting electronic pedal needing to be sized and ergonomically shaped to suit the compact in-cabin dimensions of the RZR XP 1000. During the product development phase, the Williams Controls team engineered a new spring design and, using its in-house rapid prototyping facilities, an altered lever arm.

The updated specifications for the new electronic throttle also included the use of an integrated, non-contacting Hall-effect sensor providing two independent linear output signals proportional to pedal position. This sensor provided feedback directly to Polaris’ latest throttle management system to provide improved control.

What seemed like relatively simple design changes to the existing pedal actually required a complete revalidation of the Williams Controls custom pedal to ensure its suitability for both Polaris applications. This included testing it for both U.S. and European market requirements and a series of environmental assessments.

Despite some of the harshest tests ever carried out on its products – including corrosion resistance and ice water shock tests – the pedal out-performed the requirements of both companies. In fact, for the corrosion resistance test conducted in a salt fog chamber, the custom pedal far exceeded Williams Controls’ own 96 hour requirement and easily met the Polaris requirement of 336 hours. Upon completion of the environmental testing process, Williams Controls was able to provide Polaris with working samples for pre-production and field-testing, which has been completed successfully.

Commenting on the stringent testing requirements, Senior Vice President & General Manager of Curtiss-Wright’s Industrial division Kevin Rayment explains that, given the conditions Polaris vehicles have to endure, they are delighted with the results. “It’s not unusual for these recreational vehicles to be found driving through swamps or in muddy water up to the driver’s waist, so to not just pass but exceed these somewhat unique requirements is a testament to our design, engineering and manufacturing processes.”
