Case's new Patriot 2250 sprayer features efficiency and horsepower improvements

The new Case IH Patriot 2250 sprayer includes a 660 gallon capacity tank, as well as a 6% increase in horsepower output and fuel efficiency benefits provided by the SCR-only aftertreatment system.

Patriot 2250 sprayer 0598 06 15 mr 55e8c32482528
E6fe41c9 D47e 42ab B8e1 0b3727 11108797

Engineered with more muscle, the new 660-gallon-capacity Patriot 2250 sprayer features best-in-class horsepower, along with the fuel efficiency that comes with Selective Catalytic Reduction (SCR)-only emissions technology.

“Rough fields and rolling terrain can test the limits of application equipment,” says Ken Lehmann, Case IH Sprayer Marketing Manager. “We designed our new Patriot 2250 sprayer with the increased power, torque and capacities needed to push through those limits and cover more acres, more efficiently every day.”

Using a Case IH FPT 6.7-L engine, the new Patriot 2250 sprayer is rated at 175 hp — a 6% increase over the Patriot 2240 model — and peaks at an impressive 190 hp, nearly 10% higher than its Patriot 2240 counterpart. Best of all, Case IH Efficient Power frees the engine to produce more raw power and torque with less fuel while meeting Tier 4 B/Final requirements.

Additional enhancements include:

  • A new four-speed range hydrostatic drive
  • Sauer Danfoss Series 90 heavy-duty hydrostatic pumps and new front-wheel motors for on-the-go shifting
  • Increased diesel fuel and diesel exhaust fluid (DEF) capacities — more than enough to run all day
  • A completely redesigned service center — similar in layout to larger Patriot models — makes tendering the Patriot 2250 sprayer simple and efficient
  • A new, easy-open clamshell design on the rear-engine hood provides improved accessibility

A variety of options, including a new front-fill design and advanced radio features, allows greater customization to suit each operation’s unique needs. Boom choices include 60/80 ft. or 60/90 ft. and feature a parallel-link attachment for a wide range of heights. And the new Patriot 2250 sprayer is compatible with all Case IH precision ag technology offerings, including AIM Command or AIM Command PRO spray systems, AFS AccuGuide autoguidance, AccuBoom automatic boom section control and AutoBoom automatic boom height control.

The cab-forward, rear-engine configuration of the Patriot series provides optimal weight distribution. This, coupled with industry-leading suspension and an exceptional work space, helps applicators tackle short application windows.

“With the new Patriot 2250, we’ve added the power and capacity to run all day,” Lehmann says. “Just as important, we did so without sacrificing the comfort features that help the operator stay productive through those long hours.”
