Motor Spec Guide 2018

The 2018 Motor Spec Guide features hundreds of heavy-duty hydraulic motors for the on- and off-highway vehicle markets. Find the exact motor that meets your specific application needs.

March 13, 2017

Find the hydraulic motors your specific vehicle application requires with the Motor Spec Guide from OEM Off-Highway magazine. The extensive compilation of hydraulic motors from key fluid power system manufacturers and suppliers makes the Motor Spec Guide the only aggregated guide in the industry.

The full Motor Spec Guide is housed online at www.oemoffhighway.com/specguide/motors. The online interactive version allows you to sort, filter and search the entire product listing in real time, helping to tailor down the results to only the motors that make sense for your displacement range or other parameter requirements.

Contact Editor Michelle Kopier at editor@oemoffhighway.com with any questions.
