igus isense Plain Bearings

igus' isense plain bearings detects bearing wear to help plan maintenance intervals and avoid unplanned downtime.

Pm2620 1
Igus Logo 10093507

igus has developed the isense standard range for its iglidur plain bearings.

  • Integrated technology detects wear in advance and gives users a signal in good time when the wear limit is reached
  • Range includes five materials which can cover several highly stressed applications
  • Can be used in various industries including heavy-duty equipment such as forklifts or construction machines
  • Durable and lubrication-free solution
  • Enables maintenance to be planned in advance, and avoid unnecessary replacement or  unplanned machine and system failures
  • Available in three dimensions each with an inner diameter of 20, 30 and 40 mm (0.8, 1.2 and 1.6 in.) with further sizes and materials to follow
  • Four cables with oil- and media-resistant PUR outer jacket in four standard lengths of 1-10 m (3.3-32.8 ft.) connect the bearings
  • Choice between two connector types
  • Sensors measured data can be integrated by machine and equipment operators into their systems in different ways
  • Three readout units available: manually read out all plug-in points, install control unit with red/green display on machine which provides information about condition, or connect to icom.plus
  • Connection to icom.plus uses radio module to send sensor data by wireless transmission to communication module and integration of data to the IoT, cloud system or to the customer network is possible on a wire-bound basis
