Designing Circuits for the KMA36 Magnetoresistive Position Sensor

Incorporating the KMA36 magnetoresistive position sensor into vehicle designs can offer many benefits due to the sensor's low signal to noise ratio.

Measurement Specialties Kma36magnetoresistivepositionsensor

The low signal to noise ratio of the KMA36 magnetoresistive position sensor makes it an excellent candidate for replacing Hall-Effect sensors. The KMA36 offers excellent accuracy, very good repeatability and a fast response time when measuring rotation and linear position.

This white paper provides detailed circuits and schematics that will assist engineers to embed the KMA36 into their applications. Showing easy-to-use solutions for obtaining digital data or analog output, the paper covers everything from pin assignments to optional functions, to special hints.
