Delphin Technology Expert Vibro Data Acquisition and Control System

CAS DataLoggers offers the Delphin Technology Expert Vibro Data Acquisition and Control System as an all-in-one vibration data acquisition and control solution.

• Enables users to see how their products react to vibrations or operate a shaker test without needing multiple devices with their own software
• Provides high level of accuracy by capturing vibration frequencies, phase changes and amplitudes before analysis is performed
• Records time domain data and also calculates Fast Fourier Transform (FFT) spectral analysis for frequency domain results
• Can control shaker test stand through analog or digital outputs by triggering shut-off procedures, delivering email notifications, or performing other tasks if an alarm event occurs outside of the set points assigned by the user
• Configuration and measurement data are shown on touchscreen display for added convenience
• Provides high speed data acquisition, intelligent signal processing, analysis functions, local data storage and versatile communication options in a single device
• With continuous sampling even the smallest of irregularities can be recorded to the internal 32 GB data storage, making it reliable and secure
• Uses latest dual-core FPGA processor technology for extensive computations and analysis
• Compact design
• Supports high sampling rates of up to 50kHz per channel
• 24-Bit A/D converter ensures high-precision measurement
• All channels have galvanic isolation to prevent transverse distortions
• Analog inputs can accept voltage or current inputs, direct IEPE sensors or digital rotation sensors with full configuration ability present in the ProfiSignal software
• ProfiSignal is a user-friendly software system for data acquisition, analysis, visualization and automation
• Optional ProfiSignal Vibro module provides evaluation of recorded and real-time data using FFTs, cascade, time signal and orbit diagrams after data is measured and recorded
• Can be connected to PCs via LAN or USB or various serial standards and Modbus TCP/IP and ProfiBus can connect to PLC systems
• Multiple devices can be synchronized to process vibration data from many channels for large applications
• Optional integrated Wi-Fi, GSM, UMTS or LTE modules are available to extend the communication options for remote condition monitoring applications of operating rotating equipment
