BrightLoop Converters VALUE DC-DC Converters

The VALUE DC-DC converters can be used in 12, 24 and 48V architectures and with 400, 800V or higher battery ranges.

Bright Loop Converters Epc Value Release
BrightLoop Converters

BrightLoop Converters has released the VALUE DC-DC product line, a range of converters for off-highway and commercial vehicles. .

  • Utilizes GaN technology which can significantly improve performance
  • Product line is composed of two converters (M and L) respectively delivering 6 kW/300A and 12 kW/600A
  • Features smaller footprint and weight <2.20 lbs. (<5 kg) than the equivalent power converters currently available on the market
  • Features rugged and durable design to meet expectations of commercial and off-highway vehicle markets
  • Compliant with market standards such as ECE R 10, ECE R 100 and LV 124
  • Can be used in 12, 24 and 48V architectures and with 400, 800V or higher battery ranges
  • Available in single or dual output version (plus optional) with the possibility to set the output voltage by CAN between 10 and 54V, enabling some components from the vehicle such as the battery equalizer to be removed
  • Reversibility function allows precharging without the need for bulky resistors
  • Uses Efficient Power Conversion’s EPC2029 enhancement-mode gallium nitride (eGaN) FET transistors
  • EPC2029 is an 80V, 48A eGaN FET featuring a 1 mm (0.04 in.) ball pitch
  • Wide pitch allows for placement of additional and larger vias under the device to enable high current carrying capability despite the extremely small 2.6 x 4.6 mm (0.10 x 0.18 in.) footprint
  • EPC2029 has superior switching performance
