AutomationDesk 5.0

AutomationDesk by dSPACE tests application software or diagnostic functions of ECUs.

Automationdesk3 10058667
Dspace 10055308

AutomationDesk by dSPACE is a front end tool for automated hardware-in-the-loop (HIL) testing of the application software or diagnostic functions of electronic control units (ECUs).

  • Makes it easy for users to reuse tests with any HIL simulator
  • Supports the import and export of projects, tests and custom libraries as XML files
  • Signal-based test description makes it possible to quickly create and execute clear, intuitive tests
  • Enables efficient testing of complex camera-based advanced driver assistance systems (ADAS)
  • Plotter-like editor lets users intuitively describe stimulus signals and reference signals for simulation variables
  • Documentation of performed tests provides a report with vivid plots and parameter information
  • TÜV SÜD confirms suitability for testing safety-critical functions on all Automotive Safety Integrity Levels (ASIL), from ASIL A to D, as described by the ISO 26262 standard
  • TÜV SÜD certificate makes it significantly easier for users to achieve classification, qualification and validation of product development in accordance with functional safety standards ISO 26262 and IEC 61508
  • Allows remote control of MotionDesk, dSPACE's 3D animation software for validating mechatronic systems
  • Remote-control capability simplifies tasks such as testing camera-based driver assistance systems by automatically importing various customer-defined test scenarios into MotionDesk
  • Supports new ASAM XIL standard and enables simulation-system-independent test descriptions and control of electric fault simulation
  • Can be used for automated testing in all stages of software development (MIL, SIL, HIL) and with all test systems that support the ASAM XIL standard.
