Carling Technologies CKP-Series SAE J1939 CAN Customizable Keypad

Carling Technologies' CKP-Series SAE J1939 CAN customizable keypad is available with standard or custom laser etched legends and includes up to three dimmable LED function lights per button.

January 28, 2021

Carling Technologies

Ckp Series All Configurations

Carling Technologies

Compliant with SAE J1939 CAN standards, the CKP-Series from Carling Technologies is a customizable keypad with laser etched legends. In addition to the 2x6 configuration, the CKP-series is now available in 2x2, 2x3, 2x4, and 2x5 configurations.

Includes up to three dimmable LED function lights per button which also offer diagnostic feedback by blinking if there is a fault
Above and below panel sealing protection enables installation inside or outside of machine cab
Low profile design affords seamless dashboard look
Can be mounted either vertically or horizontally
Offers advantages over traditional electromechanical switches such as 1,000,000 actuation cycles, reduced wire harnessing, and easy installation
Low Current Switching
8-32V operating voltage
Designed for 12/24V systems
Tactile and audible feedback

Fill out the form below to request more information about Carling Technologies CKP-Series SAE J1939 CAN Customizable Keypad
