SLM Series Brushless Servo Motor

Exlar’s SLM Series Brushles Servo Motor line offers high torque output in the a compact package. The improved torque performance of the SLM Series motor is the result of Exlar’s T-LAM segmented motor stator design.

• Each segment contains individual phase wiring, and thus limits heat generation
• UL recognized
• Three frame sizes, 60, 90 and 115 mm, are available
• Provides continuous torque ratings from 7.6 to 176 in-lbs and speeds ranging from 3,000 to 5,000 rpm
• One, two and three stack motor stators are standard offerings
• Custom motor voltages and base speeds are available to offer maximum system flexibility
• Allows use in state-of-the-art closed loop servo systems, where electronic control of   positioning and velocity is required
• Features IP65 sealing and stainless steel shaft
• Includes MS connectors
• Provides feedback configuration for nearly all servo amplifiers
