Topcon Apollo ECU for Sprayers

Topcon has introduced the Apollo ECU for sprayers which is configurable to support all types of boom sprayers.

Topcon Rogator AGI4 56bba2f00d43d

Topcon Precision Agriculture announces the latest addition to its Apollo ECU (electronic control units) line of application rate controller solutions, the Apollo ECU for sprayers.

  • Supports Topcon Horizon software running on the X30 and X25 consoles
  • Fully configurable to support all types of boom sprayers, including both flow and pressure-based liquid control and proportional and servo-based regulation drive options
  • Includes multi-line support for up to four lines with automatic “on-the-fly” switching between lines, allowing wider range of application rates while keeping desired droplet size of spray pattern
  • Dedicated fence-jet nozzle support allows compensation for additional fence-jet or end-row nozzles, so the correct rate is applied across the entire boom
  • User-defined chemical mix system enables tracking and application reporting paired with a new “recipe wizard” that calculates chemical proportions for each tank, removing the need for manual calculations
  • Supports 100-plus sections, which is designed to improve accuracy of auto section control (ASC) to better match needs of wide swath widths
  • Directly drives both two- and three-wire section valves, as well as balanced-section valves to meet all sprayer configurations with the same hardware
  • Ability to use Topcon VDC (vehicle display controller) for section switching allows operator to pre-assign buttons and rotary knob — eliminating need to reach to the touchscreen to control the sprayer
  • Topcon KP-12 keypad can be installed externally on the sprayer or in the cab with dedicated keys for each sprayer function, allowing control from outside the cab
