ETAS and A&D Technology integrate tools for reduced test cell time and costs

A&D Technology has integrated its ORION automated calibration tool with ETAS ASCMO DoE software to help minimize the time and costs associated with running test cells.

ETAS ASCMO web 56337928d2e11

ETAS and A&D Technology announce the integration of their products ETAS ASCMO and ORION. Both products on their own accelerate the often tedious automotive calibration procedures by automating the process and reducing the number of necessary data points to be acquired. In combination, the two products shorten the process even more.

Test cell time is expensive, and running a large number of Design of Experiment (DoE) points takes a long time. Integrating A&D’s ORION with ETAS’ ASCMO DoE tool provides a way to minimize both time and cost by indicating when the model quality is high enough to yield accurate results. Monitoring the model quality throughout the data collection enables users to stop the entire process early, eliminating superfluous measurements.

ETAS ASCMO is a model-based calibration software that automatically generates DoE test plans and enables the development of very accurate data-based models. Once created, these models can be used to optimize parameters of real systems such as the control parameters of engine ECUs and also as plant models in different simulation environments (e.g. Simulink or HIL Systems). Both steady state and dynamic/transient behaviors can be captured.

The ORION automated calibration tool facilitates the calibration process by taking control of both the ECU calibration system and the test cell control system to run experiments as part of an automated process. Using a user-friendly GUI and a Design of Experiment (DoE) as input, the user defines a sequence of actions for completing the calibration task. ORION then commands the test cell control system and the calibration system to run the sequence as defined. Data is collected as directed to characterize the engine, and then output after the test to the next step in the model-based calibration process.

“Integrating ETAS ASCMO with ORION is a logical next step in engine base calibration,” says Tobias Gutjahr, Program Manager at ETAS Inc. “Knowing exactly that the desired model quality has been achieved takes the guesswork out of the DoE test planning and measurement campaign.”
