Eaton Introduces Updates to X20 Portfolio at CONEXPO/IFPE 2017

Updates Eaton has made to its X20 portfolio include electronic displacement control across all displacements and new torque control for the 620 Series pumps.

X20 220 Piston Pump
X20 220 Piston Pump
Eaton
Logo Eaton 10933210

Power management company Eaton announces a series of updates to the company’s X20 portfolio of open circuit piston pumps, including electronic displacement control across all X20 displacements, an updated pressure/flow control, and a new torque control for the 620 Series pumps.

“At Eaton, we are continually innovating to meet our customers’ needs, and the latest updates to the X20 portfolio will help machine designers improve equipment accuracy and safety,” says Sonya Anderson, Product Manager, Mobile Open Circuit Piston Pumps, Eaton.

The electronic displacement control (EDC) varies displacement in proportion to the current signal sent to the EDC solenoid, providing greater flexibility in machine design, enhanced safety and improved productivity by providing direct control over the displacement of the pump. This allows multiple functions with different system requirements to operate in their most efficient state, while delivering the most efficient use of the power available.

Additional benefits of the X20 pump control include the ability to replace load sense with EDC and achieve low system losses by commanding pump flow to match the load requirements as determined by the vehicle electronic control unit (ECU).

The X20 portfolio EDC is available on all displacements from 28 cubic centimeters (cc) to 98 cc with two different configurations, default to full displacement or default to zero displacement upon loss of electronic signal.

The new torque control feature, available on the 74 cc and 98 cc displacements, limits the torque required by the pump based on the setting, similar to Eaton’s industry-leading PVH Series design. By limiting the peak input torque demand across the range or pressures, speeds, and temperatures, the pump prevents engine stalling while maximizing the use of the engine power, thus reducing fuel consumption in applications such as telehandlers, excavators and forestry equipment.

The externally adjustable torque setting simplifies adjustment as compared with other products that require disassembling the pump to change settings. The torque control feature can be configured with all other X20 controls except EDC and is available with an optional minimum displacement limiter, which will override the controls to ensure a minimal flow.

“The updated X20 pump with torque control is designed with hyperbolic power limitation, allowing the pump to maintain a constant torque limit exactly rather than approximating the limit using springs – adding efficiencies on top of efficiencies,” adds Anderson. “Eaton is also excited to announce an improved next generation compensator (NGC) to replace the existing load sense control on all displacements. The NGC is faster responding, tunable to system requirements through orifices in the control, and more stable and compact.”

Additionally, all pumps in the product line are now available with auxiliary mount capabilities, giving customers the option for tandem pump configurations.
