FEMA Corporation Force Motor Suspension Technologies

FEMA Corp.'s rectilinear flat spring suspended force motor system eliminates nearly all friction within a servo valve.

February 4, 2020
FEMA Corporation
Suspended Armature 2500px

FEMA suspended armature technology and associated features have been successfully integrated into hundreds of products and applications in multiple markets including agriculture, construction, industrial, mining, automotive, marine and military.

This white paper describes the basis and evolution of FEMA Corporation’s force motor electro-hydraulic suspension technology and how it is applied to products and applications today.
