Model 7264G MEMS Accelerometer

Endevco Corp.'s Model 7264G damped MEMS accelerometer for critical shock testing applications.

Model7264gmemsaccelerometer 10058705
Endevcocorp 10056702

Endevco Corp. has introduced Model 7264G, a patented, damped MEMS accelerometer for crash sled, rough road and other critical shock testing applications.

  • Full bridge with two fixed resistors to facilitate shunt calibration
  • Sensing elements are housed within a rugged, lightweight aluminum
  • Total weight 1.4 grams
  • Full scale output is 400 mV with 10V DC excitation
  • Available with less than 1% transverse sensitivity ("T" option) and less than ±25 mV zero measurand output ("Z" option)
  • Shock resistance of up to 10,000 g in any direction; range of +2,000 g full scale
  • Meets SAEJ211 and SAEJ2570 specifications for instrumentation for vehicle impact testing, as well as multiple other global automotive testing standards
