AutoVue Lane Departure Warning System

Bendix's AutoVue Lane Departure Warning System automatically alerts vehicle operators when they unintentionally drift into another lane.

Autovuewindshieldcameraandillu 10695183

Bendix Commercial Vehicle Systems (Bendix CVS) LLC has added the AutoVue Lane Departure Warning (LDW) System to its portfolio of commercial vehicle safety technologies.

  • Vision-based system that links a camera with a 60-degree field of view to an onboard computer
  • Uses image recognition software to track visible lane markings
  • Continually monitors a vehicle’s position and detects when it begins to drift toward an unintended lane change
  • Emits distinctive “rumble strip” or other audible warning to alert driver to make a correction when unintential lane change detected
  • Effective day and night, and in most weather conditions where lane markings are visible – even in low-visibility situations such as fog or rain
  • Recognizes both solid and dashed shoulder lines, centerlines and lines between lanes, even if they are heavily faded
  • When operating on snow-covered roadways, system senses it can't see lines, goes into a disabled state, and notifies driver by lighting up orange reduced-function light
  • Optimized to nearly eliminate false alarms by sensing activated turn signal for planned lane changes and disabling warnings when speed is less than 37 mph
  • Alert sounds when vehicle drifts in opposite direction of activated turn signal
  • Can be linked to SafetyDirect fleet management web portal
