Virtual ECU Testing with dSPACE Offline Simulator

May 21, 2012

Vet Off Highway 3x3inch 01 120 10719233

Dspace 10055308

With virtual ECU testing (VET), dSPACE customers can use virtual ECU models for testing and validation throughout the ECU development process.

Software components (SWCs) are already available, combined to create a virtual ECU model, then tested and validated in offline simulation on a standard PC
Allows developers to investigate real-world issues such as task scheduling, the behavior of the basic software, and communication behavior on a virtual CAN bus

Fill out the form below to request more information about Virtual ECU Testing with dSPACE Offline Simulator
