HPS Series High Pressure Premium Switches

Honeywell introduces its HPS Series High Pressure Premium Switches featuring a two million life cycle rating and IP67 environmental rating.

Honeywell Hpsserieshighpressur 10856974

Honeywell introduces its HPS Series High Pressure Premium Switches featuring multiple port and termination options to improve equipment uptime, simplify rapid design and assembly, and reduce total production costs for OEM customers.

  • Includes two million life cycle rating and IP67 environmental sealing
  • Offers durable, reliable electromechanical gauge pressure on/off capabilities
  • Available with either single pole single throw (SPST) normally open or normally closed circuitry, or single pole double throw (SPDT) circuitry
  • For use in rugged transportation and industrial applications that require the making or breaking of an electrical connection in response to a pressure change of the system media
  • Designed utilizing a building block approach that enables easy, rapid assembly
  • Provides wide pressure switching point range of 150 to 4,500 psi (10.34 bar to 310.26 bar)
  • Features proof pressure rating of 10,000 psi (689.48 bar) and burst pressure rating of 20,000 psi (1378.95 bar) to reduce field failures
  • IP67 sealing rating ensures media ingress will not create switch failure
  • Compatibility with various media including petroleum-based hydraulic fluids (engine oil, gasoline, diesel, transmission fluid, etc.), pressurized air, water, mineral oil-based brake fluid and more
  • A wide selection of terminations available including spade terminals, screw terminals, Deutsch DT04-3P, AMP Superseal 1.5, cable, cable with Deutsch DT04-3P and many more
  • Operating temperature range of -40 to 120 C (-40 to 248 F) allows for use in a variety of environments
  • Features switching point accuracy of up to ±2%, providing efficient operation of equipment
  • Switching capability of 5 mA to 5 A allows for potential use in a wide range of applications
