PTAM27L Series Inclinometer

ASM Sensors offers a MEMS-based inclinometer for single and dual axis tilt angle measurement.

August 12, 2010
ASM Sensors Inc.
Ptam27l 10165125
Asmsensors 10055038

ASM Sensors Inc. offers the PTAM27L Series inclinometer, which uses MEMS technology for single and dual axis tilt angle measurement.

  • Compact, flat housing is 10mm tall
  • Single axis: measurement ranges span from +/-15° to +/- 180°, increments of 15°
  • Dual axis: measurement ranges span from +/-15° to +/- 60°, increments of 15°
  • Wear-free sensing technology offers high resolution, is shock resistant
  • Housing is rated IP64
  • Several analog outputs, corresponding excitation voltages available
