Novotechnik Vert-X 2900 Series Angle Sensors

The Novotechnik Vert-X 2900 Series has a measurement range of 0-360 degrees with repeatability of 0.1 degree.

Novotechnik Vert X2900 Series

Novotechnik U.S. introduces the Vert-X 2900 Series of sensors that measure angular position.

  • Available in single or redundant versions
  • Elongated holes make mounting easier
  • Users can specify configurations including start- and end-angles for less than 360 degrees maximum range, index point, cw or ccw indication and non-linear curves
  • Measurement range is 0-360 degrees with repeatability of 0.1 degree
  • Mechanical range is 360 degrees continuous
  • Available analog outputs are 10-90% of supply voltage and 5-95% of supply voltage
  • Sample rate up to 5 kHz
  • Sealed to IP67
  • Life is ≥50 million movements and MTTF is over 650 years
  • Suited for industrial, medical and off-highway vehicle applications
  • Operating temperature range of -40-125 C (-40-257 F)
  • High immunity to emissions – meeting or exceeding five EN 55022 and EN 61000 standards.
