Master Bond EP48TC Epoxy

Two component epoxy with ultra low thermal resistance and superior electrical insulation properties

EP48TC 55538624bebd0
Grey Red2line270x49 10342602

Master Bond's EP48TC material utilizes a unique combination of special high thermal conductive fillers and is capable of being applied in bond lines as thin as 10-15 microns resulting in low thermal resistance. The lower the thermal resistance, the better it is for heat transfer properties.

  • Forgiving 100 to 40 mix ratio by weight, or 100 to 50 by volume
  • Upon mixing, it has a long open time with a paste consistency
  • Epoxy cures at room temperature in 4 to 7 days or in 4-6 hours at 150 to 200 F; recommended cure is overnight at room temperature followed by 3 to 5 hours at 150 to 200 F
  • Bonds well to a variety of substrates, including metals, composites, glass, ceramics and many plastics
  • Low coefficient of thermal expansion
  • Low shrinkage upon curing
  • Electrical insulation properties over the temperature range of -100 to 300 F
  • Tensile lap shear strength ranging from 900 to 1,100 psi
