Master Bond EP17HT-100 Single-Part Epoxy

Master Bond's EP17HT-100 epoxy cures within 60-90 minutes at temperatures between 200 and 220 F.

EP17HT 100 57100b7741e54
Grey Red2line270x49 10342602

Master Bond EP17HT-100 is a single-part epoxy system formulated for potting, encapsulation, bonding and sealing applications.

  • Cures in 60-90 min. at 200-220 F (93.33-104.44 C)
  • Curing can be accelerated at higher temperatures
  • Low heat curing schedule is useful in bonding applications involving temperature sensitive substrates in the aerospace, electronic, optical and other high-tech industries
  • Moderate viscosity compound
  • Features good flow properties
  • Can be cast in sections up to 1/2 in. thick
  • Not premixed and frozen, and has unlimited working life at room temperature
  • Reliable electrical insulator offering volume resistivity of >1015 ohm-cm
  • Dimensionally stable
  • Bonds well to metals, composites, ceramics, glass and many plastics
  • Tensile lap shear strength exceeds 2,700 psi (186.16 Bar) at ambient temperatures after being post cured for several hours at 350-400 F (176.67-204.44 C)
  • Features chemical resistance to oils, fuels, acids, bases, water and many solvents
  • Thermal conductivity is 4-5 BTU·in./(hr·ft.2·F) [0.58-0.72 W/(m·K)]
  • Service temperature range is -100-500 F (-73.33-260 C)
  • Naturally yellow-tan in color, but others are available
